Description
Applicable range
Daily chemical industry，medicine，plastic，electroplating，electronics，chemical industry，food processing，freezing，etc.
Performances and features
Function：The lowest water output temperature canbe 7℃ to rapidly cool the materials and guarantee material luster.Especially for cooling products such as detergent，ointment，etc.
Intelligence：The intelligent microcomputer touch screen integrated control system is adopted，which. The cooling tower starting circuit is preserved to monitor the unit operation in an all-round way.
High efficiency：The advanced high efficiency screw compressor is equipped with high quality condenser and evaporator.All products have passed the test by national inspection system，conforming to national standards.
Safety：It is provided with safety protection measures for operation of various units to ensure unit operation and safe use by customers.
Beautiful appearance：The unit adopts integral design with beautiful appearance.
Reliability：It is featured by stable performance，low noise and long service life.
| Technical parameter | ||||||||
| No. | MaterialVolume (T) |
Unit Disposing Capacity (T/H) |
Initial Temperature (℃) |
Final Temperature (℃) |
Temperature Drop Difference (℃) |
Calculated Cold Load (kw) |
Affluence Factor(1.30) | Designed Cooling Capacity (kw) |
| 1 | 1.00 | 1.00 | 80.00 | 30.00 | 50.00 | 58.15 | 1.30 | 1.30 |
| 2 | 2.00 | 2.00 | 80.00 | 30.00 | 50.00 | 116.30 | 1.30 | 1.30 |
| 3 | 3.00 | 3.00 | 80.00 | 30.00 | 50.00 | 174.45 | 1.30 | 1.30 |
| 4 | 4.00 | 4.00 | 80.00 | 30.00 | 50.00 | 232.60 | 1.30 | 1.30 |
| 5 | 5.00 | 5.00 | 80.00 | 30.00 | 50.00 | 290.75 | 1.30 | 1.30 |
